The modular online UPS, single cabinet power rating covers from 100kVA to 600kVA, provides the highest power density of 100kW power modules in 4U height, 4 units can be paralleled for capacity maximum up to 3.2MW. With the patent of Battery Neutral Free design, the RM series deliver the best combination of reliability, hot swappable and flexibility.

  • Low-carbon & Green

This series 3 level inverter, fully digital control. Achieving the input power factor ≥0.99, input THDi ≤3%, leading overall efficiency up to 96%.

  • Wide Range of the battery number

Support 30-48 pcs batteries (settable).
Shared battery pack in parallel UPS system.
Support Lithium battery.
Battery N line free patent.

  • High Power Density

The 600kW system can reach to 3.2MW.
Power module: the single module power density 100kW/4U.
Meet the large data center application site.

  • LCD screen with IOT & intelligent monitoring

10-inch color touch screen with new display style.
Support IOT and intelligent data monitoring.
Provide users intuitive display while reducing human fault.
Record maximum 2000 history logs.

  • All-round intelligent detection

Monitoring the operating status of critical component, able to set early warning.
Record the rectifier/inverter abnormal info of the power module and catch the waveform which can be exported to computer by USB.

High system capacity up to 3.2MWPower Module
There are 6 slots for power modules, easily achieve module redundancy.


Download specification here
